| 轴承型号 |
基本尺寸 |
基本额定载荷(kN) |
重量(kg) |
| dxDxT |
动(Cr) |
静(Cor) |
| 93800D/93125-93127D |
203.2x317.5x266.7 |
2400 |
4850 |
76.3 |
| 67986D/67920-67921D |
206.375x282.6x190.5 |
1030 |
2830 |
34.4 |
| M244249DW/M244210-M244210D |
220.662x314.325x239.712 |
2160 |
4900 |
60.2 |
| EE127094D/127138-127139D |
221.224x355.498x228.6 |
2100 |
4900 |
81.8 |
| LM245149D/LM245110-LM245110D |
228.6x311.15x200.025 |
1560 |
3650 |
43.9 |
| EE529091D/529157-529158XD |
228.6x400.05x296.875 |
3300 |
5650 |
148 |
| EE127097D/127135-127136D |
241.478x349.148x228.6 |
2050 |
4350 |
71.9 |
| LM247748DW/LM247710-LM247710D |
244.475x327.025x193.675 |
1740 |
4050 |
42.7 |
| M249748D/M249710-M249710D |
254x358.775x269.875 |
2720 |
6050 |
88.9 |
| HM252348D/HM252310-HM252310D |
260.35x422.275x314.325 |
4100 |
7900 |
182 |
| LM451349DW/LM451310-LM451310D |
266.7x355.6x230.188 |
1950 |
5800 |
63.9 |
| K76589/K76520-K76520D |
266.7x355.6x230.188 |
1700 |
4800 |
64.5 |
| M252349DW/M252310-M252310D |
269.875381x282.575 |
2930 |
7550 |
105 |
| EE135111DW/135155-135156DW |
279.4x393.7x269.875 |
2880 |
6200 |
103 |
| M255449DW/M255410-M255410D |
288.925x406.4x298.45 |
3400 |
8150 |
125 |
| EE330116D/330166-330167D |
292.1x422.275x269.875 |
3450 |
7950 |
126 |
| HM256849D/HM256810-HM256810D |
300.038x422.275x311.15 |
3700 |
9400 |
142 |
| M757448D/M757410-M757410D |
304.648x438.048x280.99 |
3000 |
6650 |
130 |
| M257149D/M257110-M257110D |
304.8x419.1x269.875 |
2850 |
6800 |
112 |
| M257248DW/M257210-M257210D |
304.902x412.648x266.7 |
2930 |
7000 |
102 |
| M757449DW/M757410-M757410D |
305x438.048x280.99 |
2980 |
6600 |
129 |
| LM258648DW/LM259610-LM258610D |
317.5x422.275x269.875 |
2980 |
8100 |
104 |
| HM259049D/HM259010-HM259010D |
317.5x447.675x327.025 |
4650 |
10700 |
163 |
| M260149DW/M260110-M260110D |
330.2x444.5x301.625 |
3550 |
9600 |
134 |
| EE138131D/138172-138173XD |
330.302x438.023x247.65 |
2500 |
7300 |
109 |
| HM261049DW/HM261010-HM261010D |
333.375x469.9x342.9 |
4100 |
10100 |
186 |
| LM761648DW/LM761610-LM761610D |
341.312x457.098x254 |
2350 |
7400 |
112 |
| EE536136D/536225-536226D |
342.9x571.5x342.9 |
6200 |
11500 |
366 |
| EE971355D/972100-972103D |
342.9x533.4x307.985 |
4650 |
8750 |
239 |
| LM761649DW/LM761610-LM761610D |
343.052x457.098x254 |
2670 |
7350 |
110 |
| HM262749D/HM262710-HM262710D |
346.075x488.95x358.775 |
4800 |
12400 |
221 |
| M262449D/M262410-M262410D |
347.662x469.9x292.1 |
2600 |
7950 |
142 |
| LM262449DW/LM262410-LM262410D |
347.662x469.9x260.35 |
3750 |
10100 |
129 |
| M263349D/M263310-M263310D |
355.6x488.95x317.5 |
3150 |
10000 |
177 |
| HM265049DW/HM265010-HM265010D |
368.3x523.875x382.588 |
6200 |
14800 |
274 |
| EE231475D/231975-231976D |
374.65x501.65x250.825 |
3120 |
7550 |
141 |
| HM266449DW/HM266410-HM266410CD |
384.175x546.1x400.05 |
6120 |
16400 |
310 |
| LM665949DW/LM665910-LM665910D |
385.762x514.35x317.5 |
4150 |
11000 |
189 |
| LM767749DW/LM767710-LM767710D |
406.4x546.1x288.925 |
4200 |
10000 |
186 |
| M267949D/M267910-M267910XD |
406.4x565.15x381 |
5900 |
15200 |
298 |
| EE833161D/833232-833233D |
406.4x590.55x400.05 |
6850 |
16300 |
371 |
| EE234161D/234215-234216D |
406.4x546.1x268.288 |
4150 |
9450 |
182 |
| M667947DW/M667910-M667910D |
409.575x546.1x334.962 |
4700 |
11600 |
206 |
| M268749D/M268710-M268710D |
415.925x590.55x434.975 |
5400 |
16500 |
369 |
| LM869449DW/LM869410-LM869410D |
431.8x571.5x279.4 |
3550 |
9500 |
199 |
| EE931070D/931250-931251XD |
431.8x635x355.6 |
6500 |
14500 |
386 |
| M270749DW/M270710-M270710D |
447.675x636x463.55 |
8100 |
21800 |
486 |
| L770847DW/L770810-L770810D |
457.2x596.9x276.225 |
4400 |
10500 |
202 |
| M272749D/M272710-M272710D |
479.425x679.45x495.3 |
9850 |
25000 |
586 |
| LM272249DW/LM272210-LM272210D |
482.6x615.95x330.2 |
4860 |
15200 |
252 |
| M272647DW-M272610-M272610D |
482.6x647.7x417.512 |
7200 |
19800 |
401 |
| LM772749DW/LM772710-LM772710D |
489.026x634.873x320.675 |
4750 |
12000 |
249 |
| M274149DW/M274110-M274110D |
501.65x711.2x520.7 |
9690 |
26900 |
687 |
| EE641198D/641265-641266D |
501.65x673.1x400.05 |
7000 |
19000 |
687 |
| LM274049DW/LM274010-LM274010D |
508x695.325x415.925 |
5800 |
19600 |
464 |
| EE531201D/531300-531301XD |
508x762x463.55 |
9800 |
27000 |
750 |
| LM274449DW/LM274410-LM274410D |
514.35x673.1x422.275 |
7000 |
21000 |
408 |
| LM275349D/LM275310-LM275310XD |
519.112x736.6x536.575 |
10800 |
30000 |
748 |
| LM275349D/LM275310-LM275310XD |
520.7x711.2x400.05 |
7200 |
19500 |
459 |
| M276449DW/M276410-M276410D |
536.575x761.873x558.8 |
10800 |
31500 |
832 |
| LM377449D/LM377410-LM377410D |
558.8x736.6x409.575 |
6430 |
20500 |
460 |
| EE8432DW/843290-843291D |
558.8x736.6x322.265 |
6200 |
16000 |
372 |
| M278749DW/M278710-M278710D |
571.5x812.8x593.725 |
11800 |
31500 |
998 |
| LM778549DW/LM778510-LM778510D |
584.2x762x396.875 |
7500 |
22300 |
486 |
| EE665231D/665355-665336D |
584.2x901.7x523.08 |
12800 |
27500 |
1250 |
| LM278849D/LM278810-LM278810D |
585.788x771.525x479.425 |
10000 |
29800 |
621 |
| M280049D/M280010-M280010D |
595.312x844.55x615.95 |
17200 |
38500 |
1180 |
| M280249DWA6/M280210A6-M280210D |
603.25x857.25x622.3 |
14000 |
38900 |
1168 |
| EE649241D/649310-649311D |
609.6x787.4x361.95 |
7100 |
22000 |
460 |
| M280349D/M280310-M280310D |
609.6x863.6x660.4 |
14800 |
41000 |
1230 |
| M281049D/M281010-M281010D |
635x901.7x654.05 |
15000 |
44500 |
1430 |
| LM281049DW/LM281010-LM281010D |
646.112x857.25x542.925 |
11300 |
33500 |
859 |
| M281649D/M281610-M281610D |
657.225x933.45x676.275 |
16500 |
48500 |
1580 |
| L281149DW/L281110-L281110D |
660.4x812.8x356.125 |
5300 |
19800 |
403 |
| LM281849DW/LM281810-LM281810D |
679.45x901.7x552.45 |
12800 |
38500 |
980 |
| M282249D/M282210-M282210D |
682.625x965.2x701.675 |
17400 |
50000 |
1714 |
| EE655271DW/655345-655346D |
685.8x876.3x352.425 |
7500 |
19800 |
506 |
| LM282549DW/LM282510-LM282510D |
708.025x930.275x565.15 |
12000 |
38500 |
1040 |
